Type-C Connectors
USB Type-C connectors are modern, reversible connectors designed to deliver high-speed data transfer, power delivery, and enhanced versatility. They are becoming the standard interface for most electronic devices, offering significant improvements over older USB connectors such as Micro USB and USB Type-A/B.
- Description
- Reviews (0)
Description
Key Features
- Reversible Design:
- Symmetrical shape allows the plug to be inserted in either orientation, eliminating frustration during connection.
- High Data Transfer Rates:
- Supports speeds up to 40 Gbps with USB4 standards.
- Compatible with USB 3.2 and USB 2.0 for backward compatibility.
- Enhanced Power Delivery:
- Supports USB Power Delivery (PD) up to 240W (48V/5A) for charging laptops, smartphones, and other power-hungry devices.
- Universal Compatibility:
- Works across a wide range of devices, including smartphones, tablets, laptops, monitors, and accessories.
- Multi-Functionality:
- Allows data transfer, charging, and video output (e.g., DisplayPort or HDMI Alt Mode) via a single port.
Connector Structure
The USB Type-C connector has 24 pins, ensuring flexibility and improved functionality:
- Power Pins (VBUS): Provide power delivery.
- GND Pins: Common ground for current return.
- Data Pins: Used for high-speed data transfer.
- Configuration Channel (CC) Pins: Enable plug orientation detection and power negotiation.
- Sideband Use (SBU) Pins: Support alternate modes like DisplayPort or Thunderbolt.
